Moose Test
Thread Starter
Race Director
Joined: Nov 2009
Posts: 10,594
Likes: 8
From: THE Republic
Rennlist Member
Joined: May 2008
Posts: 17,181
Likes: 309
From: Somewhere in a galaxy far, far away....
Moose test.... In Newfoundland the test would be how the car handles the impact as in most cases nobody sees the moose until it is too late...
The moose typically end up in the front seat.
The moose typically end up in the front seat.
Admin
Lifetime Rennlist
Member
Lifetime Rennlist
Member
Joined: Dec 2001
Posts: 11,004
Likes: 133
From: Athens
Reply from PORSCHE
http://teknikensvarld.se/porsche-mac...e-test-162276/
The brake intervention shown in the video is a deliberately applied intervention to prevent the car from rolling over. This is called Active Rollover Prevention (ARP). The precise, momentary application of brake force to the front wheel at the outside of the bend down to the low slip range minimises cornering forces to avoid critical or instable driving conditions such as oversteer, rollover or detachment of the tyre from the wheel. Situations such as these may not be controllable by the driver.
The video shows that an understeer response is selected on purpose since it is significantly easier for the driver to control than oversteer. The function shown and the resulting driving response are explicitly desired to increase driving safety in such a highly dynamic driving manoeuvre.
In the SUV segment, Active Rollover Prevention (ARP) is state-of-the-art technology and is also used by other vehicle manufacturers.
The intensity of ARP intervention is dependent on vehicle speed and steering angle speed, among others. This means that ARP brake intervention is diminished accordingly at reduced vehicle speed or steering angle speeds. On the other hand, it means that the driving style adopted by Teknikens Värld was very demanding and resulted in the safety function being triggered.
Active Rollover Prevention is permanently active, irrespective of whether Porsche Stability Management (PSM) is on or off. If PSM is on, ARP intervention is significantly diminished since PSM brake interventions to stabilise the vehicle occur much earlier or are superimposed.
The function (ARP) is applied for a maximum of 300 milliseconds, depending on the driving situation. This short intervention ensures the directional stability of the vehicle. Lateral displacement is negligible. For this reason we do not regard this driving state as critical. As the video shows, lane changing can be completed stably and safely. What is more critical in this situation is if the vehicle were to roll over or the rear were to break away. The vehicle demonstrated none of these instable states (rollover, oversteer, wheel lift) at any time.
Porsche uses a comprehensive dynamics test programme which the Macan completed successfully. The driving manoeuvres performed include double lane change according to ISO, slalom with 10 x 18 metres and 10 x 36 metres, the VDA obstacle avoidance test which is very similar to the Teknikens Värld ”moose test”, and the NHTSA rollover safety test. All Porsche cars are designed for maximum safety based on these and other world-wide tests.
Hermann-Josef Stappen, Porsche
http://teknikensvarld.se/porsche-mac...e-test-162276/
The brake intervention shown in the video is a deliberately applied intervention to prevent the car from rolling over. This is called Active Rollover Prevention (ARP). The precise, momentary application of brake force to the front wheel at the outside of the bend down to the low slip range minimises cornering forces to avoid critical or instable driving conditions such as oversteer, rollover or detachment of the tyre from the wheel. Situations such as these may not be controllable by the driver.
The video shows that an understeer response is selected on purpose since it is significantly easier for the driver to control than oversteer. The function shown and the resulting driving response are explicitly desired to increase driving safety in such a highly dynamic driving manoeuvre.
In the SUV segment, Active Rollover Prevention (ARP) is state-of-the-art technology and is also used by other vehicle manufacturers.
The intensity of ARP intervention is dependent on vehicle speed and steering angle speed, among others. This means that ARP brake intervention is diminished accordingly at reduced vehicle speed or steering angle speeds. On the other hand, it means that the driving style adopted by Teknikens Värld was very demanding and resulted in the safety function being triggered.
Active Rollover Prevention is permanently active, irrespective of whether Porsche Stability Management (PSM) is on or off. If PSM is on, ARP intervention is significantly diminished since PSM brake interventions to stabilise the vehicle occur much earlier or are superimposed.
The function (ARP) is applied for a maximum of 300 milliseconds, depending on the driving situation. This short intervention ensures the directional stability of the vehicle. Lateral displacement is negligible. For this reason we do not regard this driving state as critical. As the video shows, lane changing can be completed stably and safely. What is more critical in this situation is if the vehicle were to roll over or the rear were to break away. The vehicle demonstrated none of these instable states (rollover, oversteer, wheel lift) at any time.
Porsche uses a comprehensive dynamics test programme which the Macan completed successfully. The driving manoeuvres performed include double lane change according to ISO, slalom with 10 x 18 metres and 10 x 36 metres, the VDA obstacle avoidance test which is very similar to the Teknikens Värld ”moose test”, and the NHTSA rollover safety test. All Porsche cars are designed for maximum safety based on these and other world-wide tests.
Hermann-Josef Stappen, Porsche
Pro
Joined: Apr 2012
Posts: 723
Likes: 4
What's with the Moose test anyway? Is Sweden really run over by Moose ?? Is it really that bad? Is the test more severe than the normal sudden avoidance test car manufactures do? Do Moose behave differently than Deer and Bears ? Swedes please chime in.
Racer
Joined: Jan 2014
Posts: 354
Likes: 221
In short: Moose behavior and avoidance is not the issue at all. The moose test is entirely structural. Moose are identified as the most severe case of a tall-legged animal with a huge body mass. If a car hits a moose/deer/elk/etc, then the bumper of the car typically sweeps the legs out from under the animal and the weight of the body impacts the windshield and A-pillars. You should be able to imagine the difference between a solid car and one that allows the 2400 pound moose to take out the entire upper structure of an inferior car.
